ZR6302G ROCK Model 4C Plus Single Board Computer
Regular price
$133.00
Sale
$142.90
Overview
The OKdo ROCK Model 4C Plus is a reliable, multifunctional and high-performing single-board computer packed with a wide range of class?leading functionality, features and expansion options. An ideal choice for anyone from hobbyists to professionals who need an extremely highly specified platform with outstanding reliability. Developed by OKdo Technology in collaboration with Radxa, the board incorporates class-leading functionality suitable for multiple multimedia and industrial applications, ensuring outstanding reliability.
With the onboard On/Off power button, the ROCK 4C+ is an energy-efficient single-board computer. It also features multiple storage capabilities, such as 4GB 64-bit RAM and eMMC socket, an integrated fan control, an external antenna, an audio jack, dual-display support and two micro-HDMI ports supporting displays up to 4Kp60 resolution (1 x 2K up to 1440P@60, 1 x 4K 2.0 up to 4k@60). It's compatible with multiple software options, including Android, Debian/Ubuntu Linux, the full implementation of the Arm architecture v8A instructions set, and others. The 40P GPIO extension supports a wide range of interface options, providing the board with high connectivity capabilities, such as Bluetooth 5.0 with BLE, Gigabit Ethernet and Wireless LAN and extensive compatibility with a wide range of accessories
Note: this board has the same form factor as the R-Pi 4 and is compatible with majority of R-Pi 4 accessories, including camera modules.
Technical Features
- Rockchip RK3399T SoC
- Arm® big.LITTLE technology (Dual Cortex®-A72 frequency 1.5GHz and a Quad Cortex-A53 frequency 1.0GHz)
- Arm Mali T860MP4 GPU, supporting OpenGL® ES 1.1 /2.0 /3.0 /3.1 /3.2, Vulkan® 1.0, Open CL® 1.1 1.2, DirectX® 11.1
- Dual Arm Cortex M0
- Dual channel 4GB 64bit LPDDR4
- eMMC connectors
- Display supporting mirror and extended modes
- Dual micro-HDMI
- MIPI DSI
- H.265/VP9 (HEVC) hardware decode (up to 4Kp60)
- H.264 hardware decode (up to 1080p60)
- USB TypeC power input
Interfaces
- 802.11 b/g/n/ac (WiFi 5) Wireless LAN
- Bluetooth 5.0 with BLE
- 1 x micro-SD card slot
- 2 x HDMI ports supporting displays up to 4Kp60 resolution and 2Kp60
- 2 x USB2 HOST ports
- 1 x USB3 OTG/HOST port, 1x USB3 HOST port
- 1 x Gigabit Ethernet port (supports PoE with addon PoE HAT)
- 1 x camera port (2lane MIPI CSI)
- 1 x display port (4lane MIPI DSI)
- 40 x user GPIO supporting a wide range of interface options: 2 x UART, 2 x SPI bus, 2 x I2C bus, 1 x PCM/I2S, 1 x SPDIF, 1 x PWM, 1 x ADC, 6 x GPIO, 2 x 5V DC power in, 2 x 3.3V power pin
Supported software
- Full implementation of the Arm architecture v8A instructions set, Arm NEON Advanced SIMD (single instructions, multiple data) support for accelerating media and signal processing
- Armv8 cryptography extensions
- TrustZone® technology support
- Debian/Ubuntu Linux support
- Android 7.1/Android 5.0/Android 10/Android 11 support
- GPU enabled Al stack
- Hardware access/control library for Linux/Android
- Virtually interchangeable with a Raspberry Pi 4B 4GB
Features
- On board on/off power button
- Integrated fan control forthermal management
- Dual-display support
- Two micro-HDMI ports
- Supports display resolutions up to 4K @ 60hz (1 x 2K up to 1440P@60, 1 x 4K 2.0 up to 4k@60)
- Multiple connectivity capabilities so less add on hardware required, including Bluetooth 5.0 with BLE, Gigabit Ethernet & Wireless LAN
- A 40P GPIO expansion header provides extensive compatibility with a wide range of accessories
- Get more multiple memory options, including 4GB RAM and a speed eMMC socket
- Compatible with most R-Pi 4 accessories, including cases, cameras and HAT modules
Specifications
Processor
- 64bits hexa core processor
- Rockchip RK3399-T
- Dual Cortex-72, frequency 1.5GHz with qual Cortex-A53, frequency 1.0GHz
- Mali T860MP4 gpu, support OpenGL ES 1.1/2.0/3.0/3.1/3.2, Vulkan 1.0, Open CL 1.1 1.2, DX11.
Memory
- LPDDR4
- 64bit dual channel LPDDR4@3200Mb/s, 1GB/2GB/4GB optional
Storage
- eMMC connector
- ?SD card (?SD slot supports up to 256 GB ?SD card)
Display
- One Micro HDMI 2K up to 1440P@60
- One Micro HDMI 4K 2.0 up to 4k@60
- MIPI DSI 4 lanes via FPC connector
- Only two of HDMI 2k, HDMI 4K and MIPI DSI can work at the same time.
- 3.5mm jack HD codec that supports up to 24-bit/96KHz audio.
Camera
- MIPI CSI 2 lanes via FPC connector, support up to 800 MP camera (0.3mm pitch connector).
Wireless
- 802.11 ac wifi
- BT 5.0
- with external antenna
USB
- Supported USB Standards: USB 3.0, USB 2.0
- USB Port Types: USB Type A, USB Type C
- Number of USB ports: 5 ports
Ethernet
- GbE LAN with Power over Ethernet (PoE) support
- additional HAT is required for powering from PoE
IO
- 40-pin expansion header
- 2 x UART
- 2 x SPI bus
- 3 x I2C bus
- 1 x PCM/I2S
- 1 x SPDIF
- 2 x PWM
- 1 x ADC
- 6 x GPIO
- 2 x 5V DC power in
- 2 x 3.3V DC power in
Lan Details
- LAN Standard: 1000BASE-T (10/100/1000Mbps)
- LAN Port Type: RJ45
- Number of LAN Ports: 1 ports
General
- Power: USB C 5V/3A
- External port type: GPIO 40pin
- Digital Storage Details: Included capacity 4GB
- Supported Wi-Fi Modes: 802.11ac
- CPU: 64-Bit Quad Core ARM Cortex-A72 Processor
- RAM: 8GB
- Bluetooth Version: V5.0
- Dimensions: 86L x 11H x 57Wmm
-
Weight: 50g
*Specifications are subject to change without notice
