Cabac 10m 360 Deg 1 Ch LED 400W Ceil Mount Lighting Device Control Presence Detector
Regular price
$129.90
Sale
$139.95
Designed as a single load for controlling lighting devices, the CPD-360 is a high-performance relay for all types of lighting fixtures. The omni-directional quad element detector is integrated with the unique lens to provide "no dead spot" zones and superior sensitivity in its 360-degree detection coverage. The device features down light construction to enable quick and easy mounting in various ceiling board thicknesses.
- The adjustable sensor head is capable of 30 degree downward and 350 degrees clockwise/anticlockwise rotation, allowing the detection angle to be set as required.
- The detection beams are well distributed and concentrated over the detection coverage, allowing the device to detect subtle movements.
- A built-in red LED works as an indicator for simplifying test operation.
- RJ-12 plug and socket make the sensor and power box quick and easy to install.
- The hinged top covers of the power box are convenient for quick connection.
Features
- 360-degree ceiling mount presence detector designed for controlling lighting devices, includes unique flush mount feature for easy installation
- LED 400W, AC Halogen 1000W, Incandescent 2000W, Fluorescent 900VA
- Manual override and auto-off timer settings from 5 seconds to 30 minutes
- Lux adjustment from 10 to 2000 lux
- 10 metre detection range and unique lens tilt feature
Operating Specifications and Technical Data
- Auto Off Timer Adjustment: TIME1 (L): Adjust from 5 seconds to 30 minutes and test & TIME2 (D1-D2): Adjust from 10 seconds to 60 minutes
- LUX Adjustment: Adjustable from 10Lux to 2000 Lux
- Detection Range: Diameter 10m at 2.5 3m
- Operating Temperature: 0 to +45 degrees Celsius
- Environmental Protection: IP40 (Sensor), IP20 (Power box)
- Circuit diagram and dimensions available, refer to the product Datasheet
Technnical Specifications
- Detection Range (m): 10
- Number of Channels: 1
- Mounting Type: Ceiling
- Surface Mount: No
- Ceiling Mount: No
- Lamp Compatibility: Incandescent, Halogen, Fluoroscent
Electrical Data
- Rated Voltage: 230 +/- 10% 50/60H
- Load I (L) for Lighting:
- 10 A (at 230 V AC, cos = 1), 3 AX (at 230 V AC, cos = 0.3)
- Incandescent Lamp: max. 2000W
- AC Halogen Lamp: max. 1000W
- LV Halogen Lamp: max. 1000VA
- Fluorescent Lamp: max. 900VA/100uF (compensated)
- Fluorescent Lamp: max. 1000VA (uncompensated)
